Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999%

Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999%

Products - PSA Nitrogen Generator
  • High Light

    Box Type container nitrogen generator

    ,

    container nitrogen generator 95%

    ,

    psa nitrogen system 99.999%

  • Purity
    95%-99.999%
  • Power(w)
    0.1kw
  • Type
    Skid-mounted
  • After-sales Service Provided
    Video Technical Support
  • Voltage
    220v/380v/50-60hz
  • Place Of Origin
    Beijing China (Mainland)
  • Dew Point
    -45ºC - -60ºC
  • Capacity
    1-3000 Nm3/h
  • Warranty
    18 Months
  • Place of Origin
    BeiJing
  • Brand Name
    cape golden
  • Certification
    CE ISO
  • Model Number
    CANL-15
  • Minimum Order Quantity
    1
  • Delivery Time
    40 day
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram

Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999%

  • Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999%
  • Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999%
  • Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999%
Get Price Contact Now

Containerized/Box-type Nitrogen Generator 95%~99.999%

Production Description:

PSA nitrogen technology utilizes two towers which are filled with carbon molecular sieve (CMS). Compressed air enters the bottom of one tower. While the smaller oxygen molecules are adsorbed by the CMS, the larger nitrogen molecules pass through the sieve and are stored. Once the CMS of the working tower is saturated with oxygen, the regeneration of the CMS in the tower starts to work by depressurizing, and while another tower is switched to start the process over again.
Customized capacity, purity and delivery pressure are also available.
Main Technical Parameters
Flow for Nitrogen : 10~12000 m3/h(20ºC,101.325kPa)
Purity for Nitrogen : ≥97~99.9995%(accordingly)
Dew Point Under Normal Pressure : ≤-45ºC(accordingly)
Pressure for Nitrogen : 0.05~0.8Mpa(accordingly )

Work Principle

PSA nitrogen technology utilizes two towers which are filled with carbon molecular sieve (CMS). Compressed air enters the bottom of one tower. While the smaller oxygen molecules are adsorbed by the CMS, the larger nitrogen molecules pass through the sieve and are stored. Once the CMS of the working tower is saturated with oxygen, the regeneration of the CMS in the tower starts to work by depressurizing, and while another tower is switched to start the process over again.



Box Type Container Nitrogen Generator PSA Nitrogen System 95%~99.999% 0

Cape-Golden PSA Nitrogen generator
Capacity (Nm³/h) Purity(%) Model
5 95 CANL-5
99 CANP-5
99.5 CANG-5
99.9 CANH-5
99.99 CANZ-5
99.999 CANHZ-5
10 95 CANL-10
99 CANP-10
99.5 CANG-10
99.9 CANH-10
99.99 CANZ-10
99.999 CANHZ-10
20 95 CANL-20
99 CANP-20
99.5 CANG-20
99.9 CANH-20
99.99 CANZ-20
99.999 CANHZ-20
30 95 CANL-30
99 CANP-30
99.5 CANG-30
99.9 CANH-30
99.99 CANZ-30
99.999 CANHZ-30
50 95 CANL-50
99 CANP-50
99.5 CANG-50
99.9 CANH-50
99.99 CANZ-50
99.999 CANHZ-50
100 95 CANL-100
99 CANP-100
99.5 CANG-100
99.9 CANH-100
99.99 CANZ-100
99.999 CANHZ-100
200 95 CANL-200
99 CANP-200
99.5 CANG-200
99.9 CANH-200
99.99 CANZ-200
99.999 CANHZ-200
300 95 CANL-300
99 CANP-300
99.5 CANG-300
99.9 CANH-300
99.99 CANZ-300
99.999 CANHZ-300
500 95 CANL-500
99 CANP-500
99.5 CANG-500
99.9 CANH-500
99.99 CANZ-500
99.999 CANHZ-500
1000 95 CANL-1000
99 CANP-1000
99.5 CANG-51000
99.9 CANH-1000
99.99 CANZ-1000
